| Type | G500 |
|---|---|
| Pressure ratio | 1:519 |
| Displacement volume (cm³) | 1,90 |
| Displacement volume (in³) | 0,12 |
| Discharge (bar) | 4500 |
| Discharge (psi) | 65250 |
| Air Drive Pressure min. (bar) | 1 |
| Air Drive Pressure min. (psi) | 14.5 |
| Air Drive Pressure max. (bar) | 10 |
| Air Drive Pressure max. (psi) | 145 |
| Weight (kg) | 13,50 |
| Flow (cfm) | 0,01 |
| Flow (l/min) | 0,39 |
| Inlet (in) | 1/4 |
| Outlet (UNF) | 9/16-18 |
| Drive Air (in) | 3/4 |
| Operating Temperature max. (°C) | 60 |
| Height (mm) | 362,00 |
| Depth (mm) | 181,00 |
| Width (mm) | 272,00 |
