| Type | G15 |
|---|---|
| Pressure ratio | 1:16 |
| Displacement volume (cm³) | 62,00 |
| Displacement volume (in³) | 3,78 |
| Discharge (bar) | 160 |
| Discharge (psi) | 2320 |
| Air Drive Pressure min. (bar) | 1 |
| Air Drive Pressure min. (psi) | 14.5 |
| Air Drive Pressure max. (bar) | 10 |
| Air Drive Pressure max. (psi) | 145 |
| Weight (kg) | 16,00 |
| Flow (cfm) | 0,45 |
| Flow (l/min) | 12,86 |
| Inlet (in) | 1 |
| Outlet (in) | 3/4 |
| Drive Air (in) | 3/4 |
| Operating Temperature max. (°C) | 60 |
| Height (mm) | 311,00 |
| Depth (mm) | 190,50 |
| Width (mm) | 272,00 |
