| Type | M189-2 |
|---|---|
| Pressure ratio | 1:440 |
| Displacement volume (cm³) | 0,60 |
| Displacement volume (in³) | 0,04 |
| Discharge (bar) | 4000 |
| Discharge (psi) | 58000 |
| Air Drive Pressure min. (bar) | 1 |
| Air Drive Pressure min. (psi) | 14.5 |
| Air Drive Pressure max. (bar) | 10 |
| Air Drive Pressure max. (psi) | 145 |
| Weight (kg) | 3,90 |
| Flow (cfm) | 0,01 |
| Flow (l/min) | 0,21 |
| Inlet (in) | 1/5 |
| Outlet (UNF) | 9/16-18 |
| Drive Air (in) | 3/9 |
| Operating Temperature max. (°C) | 60 |
| Height (mm) | 289,00 |
| Depth (mm) | 120,00 |
| Width (mm) | 115,00 |
