Valves, Fittings & Tubings - Fittings 65000 psi

Gruppenaufnahme
MAXIMATOR fittings and bolted unions of the 4,500 bar series are designed for simple and safe connection of HP pipes up to a max. pressure of 4,500 bar.
Type O.D. Tube Name Orifice
in mm
Anti-Vibration Collar 1/4 65AVFC4H
3/8 65AVFC6H
9/16 65AVFC9H
Anti-Vibration Complete Assembly 4500 bar 1/4 65AVA4H
3/8 65AVA6H
9/16 65AVA9H
Bulkhead Coupling 1/4 65BF4H 2,30
3/8 65BF6H 3,00
9/16 65BF9H 4,80
Collar 1/4 65C4H
3/8 65C6H
9/16 MCLM90
9/16 65C9H
Cross Connector 1/4 65X4H 2,30
3/8 65X6H 3,00
9/16 65X9H 4,80
Elbow-Connector 1/4 65L4H 2,30
3/8 65L6H 3,00
9/16 65L9H 4,80
Gland 1/4 65G4H
1/4 MGLM40
3/8 65G6H
3/8 MGLM60
3/8 MGLM60-22
9/16 MGLM90-30
9/16 65G9H
9/16 MGLM90
Gland Nut 1/4 65AVG4H
3/8 65AVG6H
9/16 65AVG9H
Plug 1/4 65P4H
3/8 65P6H
9/16 65P9H
Slotted Collet 1/4 65AVC4H
3/8 65AVC6H
9/16 65AVC9H
Straight Coupling 1/4 65F4H 2,30
3/8 65F6H 3,00
9/16 65F9H 4,80
Tee-Connector 1/4 65T4H 2,30
3/8 65T6H 3,00
9/16 65T9H 4,80
Tube Cap 1/4 65TC4H
3/8 65TC6H
9/16 65TC9H
Universal Safety Heads 1/4 65SH4H 2,10
3/8 65SH6H 3,10
9/16 65SH9H 4,70
